| General Information | |
|---|---|
| Product Name | Smart-Ups VT 10KVA 208V with 1 Battery Module Exp to 2 Start-UP5X8 |
| Manufacturer Part Number | SUVTP10KF1B2S |
| Product Line | Smart-UPS |
| Product Series | VT |
| Product Type | Dual Conversion Online UPS |
| Technical Information | |
| Plug / Connector Type | Hard Wire 5-wire |
| Receptacles | 1 x Hard Wire 5-wire 1 x Screw Terminal |
| Battery Information | |
| Backup / Run Time Full Load | 5.50 Minute |
| Backup / Run Time Half Load | 18 Minute |
| Typical Battery Recharge Time | 5 Hour |
| Management | |
|---|---|
| Network Management | SNMP Manageable |
| Power Description | |
| Load Capacity | 10000 VA/8000 W |
| Input Voltage | 220 V AC |
| Output Voltage | 120 V AC 208 V AC |
| Physical Characteristics | |
| Form Factor | Tower |
| Height | 59' |
| Width | 14' |
| Depth | 32' |
| Warranty | |
|---|---|
| Limited Warranty | 1 Year |
| Other Information | |
| Product Family | Smart-UPS VT |
| Load Capacity VA | 10000 VA |
| Load Capacity Watt | 8000 W |
| Input Frequency | 40 Hz to 70 Hz |
| Serial Port | Yes |
| Output Frequency | 50 Hz to 60 Hz |
| Bypass Switch | Automatic Internal Manual Maintenance Static |
| Emergency Power OFF | Yes |
| Input Current | 27 A |
| Modular Slots | SmartSlot 1 x Battery |
| Battery Chemistry | |
