ASUS new platform sever board - the supports the 45nm Multi-Core Intel Xeon processor at FSB1333MHz based on the Intel 3200 MCH features up to 8GB DDR2 800/667 memory capacity and various expansion choices.
Specification:
Mainboard Type: Servers
Mainboard Form Factor: ATX
Compatible Processors: Intel Xeon 3300/3100/3200/3000
Mainboard Chipset Type: Intel 3200
Front Side Bus: 800/1066/1333 MHz
Max Bus Speed: 1333 MHz
Video Output Type: XGI Z9s
Video Memory Installed Size: 32 MB
Compliant Standards: US (FCC CFR47 Part 15 Class B); Europe (CE EN55022 & EN55024)
Networking Type: 2 x Broadcom BCM5721 PCI-E GbE LAN
Features: Smart Fan I; Rack Ready (Rack and Pedestal dual use); ASWM2.0
Processor Max Supported Qty: 1
Processor / Socket Type: Socket 775
RAM Technology: DDR2 SDRAM
RAM Max Supported Size: 8 GB
Data Integrity Check: ECC; non ECC
Controller Interface Type: Serial Attached SCSI
Controller Interface Type (2nd): Serial ATA-300; DMA/ATA-100 (Ultra)
Expansion Slots Total (Free): 2 x PCI 32bit/33 MHz; 2 x PCI-X link; 1 x PCI-E x16 (x8 link); 1 x SO-DIMM socket for optional ASMB3-SOL
Interfaces & Connections: 1 x External Serial Port; 4 x External USB Port; 1 x VGA Port; 2x RJ-45; 1x PS/2 KB/Mouse
Width: 12 Inch
Depth: 9.6 Inch
Specification:
Mainboard Type: Servers
Mainboard Form Factor: ATX
Compatible Processors: Intel Xeon 3300/3100/3200/3000
Mainboard Chipset Type: Intel 3200
Front Side Bus: 800/1066/1333 MHz
Max Bus Speed: 1333 MHz
Video Output Type: XGI Z9s
Video Memory Installed Size: 32 MB
Compliant Standards: US (FCC CFR47 Part 15 Class B); Europe (CE EN55022 & EN55024)
Networking Type: 2 x Broadcom BCM5721 PCI-E GbE LAN
Features: Smart Fan I; Rack Ready (Rack and Pedestal dual use); ASWM2.0
Processor Max Supported Qty: 1
Processor / Socket Type: Socket 775
RAM Technology: DDR2 SDRAM
RAM Max Supported Size: 8 GB
Data Integrity Check: ECC; non ECC
Controller Interface Type: Serial Attached SCSI
Controller Interface Type (2nd): Serial ATA-300; DMA/ATA-100 (Ultra)
Expansion Slots Total (Free): 2 x PCI 32bit/33 MHz; 2 x PCI-X link; 1 x PCI-E x16 (x8 link); 1 x SO-DIMM socket for optional ASMB3-SOL
Interfaces & Connections: 1 x External Serial Port; 4 x External USB Port; 1 x VGA Port; 2x RJ-45; 1x PS/2 KB/Mouse
Width: 12 Inch
Depth: 9.6 Inch
