Tripp Lites intelligent line interactive tower uninterruptible power supply (UPS) prevents data loss downtime and equipment damage due to power outages voltage fluctuations and transient surges. Large internal batteries offer 14 minutes half load runtime and 4 minutes at full load. Runtime is expandable with optional BP48V18 external battery packs. Maintains regulated 230V nominal output without using battery power during brownouts and overvoltages from 151 to 282V. 3000VA power handling capability offers compatibility with a variety of networking telecom and other sensitive electronic applications.
Specification:
Power Device Type: UPS
UPS Technology: line-interactive
Voltage Output: AC 230 V
Voltage Input: AC 230 V
Circuit Protection: Circuit breaker
Power Device / Form Factor: External
Features: Audible alarm emergency power off LED display; Cables Included 3 x power cable Serial cable USB cable
Width: 9.25 Inch
Depth: 12 Inch
Height: 14.25 Inch
Compliant Standards: UL1778 CE 62040
Enclosure Color: Gray
Power Provided (W): 2.25 KW
Power Provided (VA): 3000 VA
Surge Suppression: Standard
Battery Type: UPS Battery
Battery Form Factor: Plug-in module
Battery / Run Time: 4 min at full load
Interfaces & Connections: Interfaces 2 x management - RS-232 - 9 pin D-Sub (DB-9) 2 x management - USB 1 x management - RJ-11
Input Connector(s): 1 x power IEC 320 EN 60320 C20
Output Connector(s): 8 x power IEC 320 EN 60320 C13 1 x power IEC 320 EN 60320 C19
Product Line: Tripp Lite SmartPro
Networking Type: Includes 4 built-in monitoring ports 2-USB & 2-DB9
Service & Support Type: 2 year product warranty
