Tripp Lites implements HDBaseT technology to transmit HDMI audio and video RS-232 Serial and IR Remote Control signals up to 328-ft. (100M) over a single Cat5e/6/6a cable. It allows an Ultra High Definition (UHD) 4Kx2K or High Definition 1080p video signal to be extended up to 328-ft. (100M) from the source. You can further expand the range and number of monitors in your installation by adding BHDBT-TR-SI-LR transceivers in between the transmitter and receiver units. The BHDBT-TR-SI-LR features a HDMI port for the connection of a monitor and can be located 328-ft. (100M) from the transmitter unit. The receiver unit can then be located the same distance from the transceiver allowing you to double the total extension distance. Up to 5 transceiver units can be inserted in between the transmitter and receiver allowing for an overall extension distance of up to 2000-ft. (600M) with a monitor located at each point in the chain.
Specification:
Device Type: Serial Extender
Interfaces: HDMI (FEMALE) X2 RJ45 (FEMALE) X2 3.5MM (FEMALE) X6
Max Transfer Distance: 100 M
Max Resolution (external): 3840 x 2160
Service & Support Type: 1 year limited warranty
RoHS: Y
Specification:
Device Type: Serial Extender
Interfaces: HDMI (FEMALE) X2 RJ45 (FEMALE) X2 3.5MM (FEMALE) X6
Max Transfer Distance: 100 M
Max Resolution (external): 3840 x 2160
Service & Support Type: 1 year limited warranty
RoHS: Y
